Xiangtuo XT-550B Remote Control Tracked Lawn Mower — Powered by Longxin 224CC Engine
The Xiangtuo XT-550B is a professional-grade remote control tracked crawler mower powered by a Longxin 224CC engine, engineered to handle slopes up to 45 degrees, dense vegetation, and demanding mowing conditions across orchards, farms, and hillside pastures. With a 550mm wide cutting deck, and intelligent electric lifting/lowering system, the XT-550 sets a new standard for powerful, safe, and efficient remote-controlled mowing.
Product Overview
The XT-550GO combines the proven reliability of a Longxin 224CC gasoline engine with a robust electric drive system, delivering powerful performance and smart control in one machine. Its 45° climbing ability makes it one of the most capable tracked mowers in its class — tackling steep hillside pastures, sloped orchards, and rough terrain that would be dangerous or impossible for ordinary mowers. The electric lifting/lowering deck and remote-controlled work lamp extend its usability into low-light and varied terrain conditions.
Key Specifications
| Specification | Details |
|---|---|
| Model | XT-550B |
| Overall Size | 960 × 930 × 560 mm |
| Total Weight | 150 kg |
| Cutting Width | 550 mm |
| Cutting Height | 20 - 150 mm (Electric Adjustable) |
| Climbing Ability | 45° |
| Walking Speed | 4 km/h |
| Engine Brand | CONCIN (隆鑫) |
| Engine Displacement | 224CC |
| Fuel Tank Capacity | 1.2 L |
| Oil Capacity | 0.6 L |
| Fuel Consumption | 1.2 L/h |
| Grass-Cutting Efficiency | 1,500 m²/h |
| Track Width | 150 mm |
| Pneumatic System | Remote Start & Stop |
| Electric Lifting/Dropping | Yes |
| Remote Work Lamp | Yes |
| Battery | 24V / 12V 12.3Ah |
| Remote Control Range | Electric Drive (see note) |
| Certification | CE |
Why Choose the Xiangtuo XT-550B?
🚀 CONCIN 224CC Engine — Proven Power & Reliability
The CONCIN 224CC is one of China's most trusted gasoline engines for agricultural machinery. With 224CC displacement, it delivers strong, consistent torque for demanding mowing tasks — cutting through tall grass, dense weeds, and light brush with ease. Loncin/Longxin engines are renowned for fuel efficiency, easy starting, and durability in outdoor environments.
🐍 45° Climbing Ability — Conquer the Steepest Slopes
The XT-550B climbs slopes up to 45 degrees — an exceptional rating that few remote control mowers can match. Whether it's a hillside pasture, sloped orchard, or uneven terrain, this tracked crawler mower maintains stability and traction where it matters most.
⚡ Electric Lifting/Dropping Deck — Smart Height Control
Unlike mowers with manual height adjustment, the XT-550B features electric deck lifting and lowering controlled directly from the remote. Adjust the cutting height from 20mm to 150mm on the fly to adapt to different grass types, terrain conditions, and mowing preferences — all without leaving your safe operating position.
💡 Remote Control Work Lamp — Mow in Any Light
The built-in remote-controlled work lamp allows you to continue mowing in low-light conditions, early mornings, evenings, or under tree canopy shade. Turn the lamp on/off from the remote for maximum visibility and safety.
🛢️ 1,500 m²/h Cutting Efficiency
With a 550mm cutting width and powerful engine, the XT-550B achieves a cutting efficiency of 1,500 square meters per hour — covering large areas quickly and effectively. At 4 km/h walking speed, it's designed for productivity as much as performance.
📱 Remote Start & Stop — Full Electric Pneumatic Control
The pneumatic system allows you to start and stop the engine remotely via the controller — no need to physically approach the mower to start it. This is especially useful after refueling or when the mower is operating in hazardous areas.
Application Scenarios
| Scenario | How the XT-550B Excels |
|---|---|
| Steep Hillside (up to 45°) | Industry-leading 45° climbing — operates safely where most mowers can't |
| Sloped Orchard | Low profile + remote control = safe mowing between tree rows on slopes |
| Large Farm / Pasture | 1,500 m²/h efficiency covers large areas quickly |
| Rough Terrain | 150mm wide tracks +600W×2 dual motors = powerful grip on rocks, roots, mud |
| Dense Tall Grass / Light Brush | CONCIN 224CC handles vegetation up to heavy growth |
| Low-Light Mowing | Remote work lamp provides visibility in shaded or early/late hour work |
Safety Features
- 45° Tilt Protection — automatic engine shutdown if mower exceeds safe angle
- Emergency Stop — instant stop from remote controller
- Remote Start/Stop — no need to physically approach running mower
- Dual Drive Motor Safety — each track independently controlled for stability
- Blade Brake — rapid blade stop when remote is released
- Remote Work Lamp — enhanced visibility for safe low-light operation
Performance Data
| Parameter | Value |
|---|---|
| Cutting Width | 550 mm |
| Cutting Height Range | 20 - 150 mm |
| Max Slope | 45° |
| Walking Speed | 4 km/h |
| Cutting Efficiency | 1,500 m²/h |
| Fuel Tank | 1.2 L |
| Fuel Consumption | 1.2 L/h |
| Estimated Runtime | ~1 hour per tank |
| Total Weight | 150 kg |
Easy Maintenance
- Tool-free blade access — change and sharpen blades quickly on-site
- Standard CONCIN parts — globally available, easy to source
- Simple track tension adjustment — accessible bolts, no special tools required
- Easy-access air filter & spark plug — routine maintenance takes minutes
- Electric deck system — no hydraulic fluid, simpler maintenance than hydraulic lift systems
- Standard CONCIN /CONCIN engine network — service support available worldwide
FAQ — Frequently Asked Questions
Q: How steep can the XT-550B climb?
A: The XT-550B is rated for slopes up to 45 degrees (approximately 100% grade) — one of the highest slope ratings in its class. Always operate within safe terrain conditions.
Q: How long can it run on one tank of fuel?
A: With a 1.2L fuel tank and consumption of 1.2L/h, runtime is approximately 1 hour per fill. For longer operations, plan for additional fuel on site.
Q: What is the cutting height range?
A: The electric deck can be adjusted from 20mm to 150mm via the remote control — suitable for short lawn grass to tall pasture.
Q: How does the electric lifting system work?
A: The deck is raised and lowered electrically via the remote controller, powered by the 24V/12V battery system. No manual adjustment or hydraulic pump needed.
Q: What is the track width?
A: The rubber tracks are 150mm wide, providing excellent weight distribution and grip on soft soil, mud, slopes, and rough terrain.
Q: Is the CONCIN 224CC engine reliable?
A: Yes. CONCIN (隆鑫) is one of the most widely used engine brands in Chinese agricultural machinery. The 224CC model is known for strong performance, fuel efficiency, and long service life.
Q: What certification does the XT-550B have?
A: The mower is certified with CE for safety and quality compliance.
Standard Package
| Item | Quantity |
|---|---|
| Xiangtuo XT-550B Mower | 1 unit |
| Remote Controller | 1 unit |
| Longxin 224CC Engine | 1 unit |
| Fuel Tank (1.2L) | 1 unit |
| 24V/12V Battery System | 1 unit |
| Remote Work Lamp | 1 unit |
| Spare Blade Set | 1 set |
| Tool Kit | 1 kit |
| User Manual | 1 copy |
| Certificate of Conformity | 1 copy |
Why Xiangtuo?
Xiangtuo is a professional manufacturer of remote control tracked lawn mowers with 10+ years of experience. The XT-550B represents our commitment to powerful, reliable, and safe mowing solutions.
- ✅CONCIN genuine engine — authentic, proven power
- ✅ 45° slope climbing — class-leading capability
- ✅ Electric lifting/lowering deck — smart remote height control
- ✅ CE certified
- ✅ OEM/ODM customization available
- ✅ 12-month warranty on main components
- ✅ Global spare parts supply and technical support
- ✅ FOB, CIF, EXW ,DDPshipping terms supported
Get a Free Quote
Ready to see what the Xiangtuo XT-550B can do for your property or operation? Contact us today for pricing, customization options, and shipping quotes.
